X, Y, Z-axis travel: 2500*800*850mm;
Worktable: 2700*800mm, heavy working load as 3000kg;
Spindle: BT50, 4500rpm, 560Nm;
ATC: chain-type, 32 station;
Use famous CNC system: FANUC, SIEMENS, etc;
Powerful vertical machining center: ideal equipments which designed to meet the machining requirements of heavy-cutting parts with multi-operating procedures.
Strong-type S series is a kind of machines which designed ot manufacture heavy-cutting work-pieces which have complicated machining procedure. The main casting of machine tool is made from high-strength cast iron material and shaped by resin sand technology with 2 ageing treatment to establish the stress.
Reasonable structure design: By thermal-symmetric and box-stiffener designing technologies, the high-speed, high-efficiency and high-accuracy machining effect could be guaranteed.
Oil cooling: Be provided with oil cooler, which can reduce the distortion of parts.
3 axes ball screw dragging device: Accurate ball screw and specified ball screw bearing.
Chain-type tool magazine: Be provided with abundant tool capacity which can greatly enhance the cutting efficiency.
Extra-load machine bed: 3-axes cast iron slideway, which has strong loading capacity of 3000kg at most.
Powerful outputting spindle box: provided high torque with low-speed for powerfull cutting
operation, which reaches 990Nm at most.
8 sliding blocks and 4 slideways: Be able to play performance at the time of instantaneous cutting, which could ascertain a high-accuracy heavy cutting effect.
Arm-type tool magazine
3 color alarm lamp
Adjustment iorn pads and fixing bolts
Auto lubrication system
Fully enclosed protection
Stainless protective pull board
Spindle center coolant
3-axis linear encoder
Tool inspection device
Workpiece inspection device
Chain-type chip conveyor
|max. work load||kg||3000|
|distance between spindle nose & table surface||mm||200-1050|
|Feed||rapid feed rate in X/Y/Z axis||m/min||15/15/10|
|cutting feed rate||m/min||4|
|tool changing time||s||3.5|
|positioning accuracy||implementation JISB6330 standard||mm||±0.008/300|
|repeatability positioning accuracy||mm||±0.005|
|Electrical total capacity||KVA||50|
|dimension & weight||length* width||mm||7360*4435|
|CNC system||FANUC 0i-MD|
10 to 20 working days after receipt of down payment,clarification of all technical and commercial items.
